Geology Science Fair Project

Soil Type and Liquefaction

Medium
Soil Type and Liquefaction | Science Fair Projects | STEM Projects
Does the type of soil under a building decide how much it sinks during an earthquake? Liquefaction (when waterlogged soil loses its strength) is one of the biggest dangers in seismic zones. You fill three pails with sand, clay, and loam. You place bricks on top, then slowly add water in 100 ml doses. You count how many doses it takes for the bricks to sink 30 mm. The results show which soil type resists liquefaction the longest.

Hypothesis

The hypothesis is that sand will require the most water before soil liquefaction occurs.

Method & Materials

You will fill each pail with a different type of soil, stack the bricks on top, draw a line to mark the sinking of the brick, and pour 100ml of water into the soil. You will repeat this process until the bricks sink or collapse.
You will need 1 pail of sand, 1 pail of clay, 1 pail of loam, tap water, 1 measuring jug, 3 bricks, 1 black marker, 1 ruler, and 1 stopwatch.

Results

The results showed that sand required the most amount of water to sink the brick, while loam soil required the least amount of water. This proved the hypothesis to be true.

Why do this project?

This science project is interesting because it shows how soil liquefaction can cause serious damage to buildings and property. It is important to understand the conditions under which different types of soil liquefy.

Also Consider

Experiment variations include filling a pail with several types of soil, compressing the soil and inverting the pail on the ground to create a mound of soil. Additionally, adding rocks or mixing different types of soil together can be done to compare the results.

Full project details

Additional information and source material for this project are available below.

Related videos

These videos explain the science behind this project and demonstrate key concepts used in the experiment.
